Name: KP3-V
Brand: MY SHOP

Description

Product Overview

KP3-V rated voltage AC 380V, frequency 50/60Hz, suitable for industrial grade three-phase distribution environment. The product is equipped with a high-precision voltage monitoring module, with a measurement accuracy error of ≤ 2% for each phase voltage, which can accurately capture voltage fluctuations in a wide range of 80V~450V. Supports custom protection thresholds for overvoltage (400V~450V adjustable, default 420V) and undervoltage (320V~360V adjustable, default 340V), as well as detection of phase loss and reverse phase sequence faults. Equipped with 1-500S recovery delay and 0.1-30s action delay adjustment, effectively avoiding the impact of frequent start stop on the equipment.
Made with industrial grade components, the electrical lifespan is up to 10 ⁵ times, the mechanical lifespan is up to 10 ⁶ times, the protection level is IP20, and it can operate stably in ambient temperatures ranging from -30 ℃ to+70 ℃ and at altitudes below 2000m. Parameter configuration can be completed through simple buttons, coupled with a dynamic display window for three-phase voltage, making operation intuitive and convenient. It is the core component that ensures the safe and stable operation of three-phase distribution systems.

Main Features

1. Comprehensive fault protection: integrating multiple protections for overvoltage, undervoltage, phase loss, and reverse phase sequence, covering common types of faults in three-phase power grids, providing a one-stop safety solution for equipment such as motors and pumps.
2. Wide range precise monitoring: Supports wide voltage range monitoring from 80V to 450V, with a measurement accuracy of ≤ 2% per phase, real-time monitoring of the power grid operation status, flexible adjustment of protection thresholds, and adaptability to different regional power grid characteristics.
3. Intelligent delay control: Dual delay parameters are independently configured to restore delay and avoid frequent start stop. Action delay ensures fast response, balancing protection sensitivity and device operation stability.
4. High reliability design: wide temperature and altitude adaptability, over a million mechanical and electrical lifetimes, ensuring long-term stable operation and reducing maintenance costs.
5. Intuitive interactive experience: Dynamic display of three-phase voltage data, one click parameter setting, simple and easy to understand operation, convenient for quickly troubleshooting power grid abnormalities.
6. Automatic recovery function: After troubleshooting, it automatically closes the power supply without manual intervention, improving the continuity and convenience of power consumption.

Application scenarios

1. Industrial production scenario: Provide protection for three-phase power equipment such as motors, water pumps, compressors, etc. in factory workshops and production lines to avoid equipment damage and production stagnation caused by abnormal voltage and phase loss.
2. Commercial building power distribution: applied to the front-end of three-phase equipment such as central air conditioning, elevators, lighting systems, etc. in shopping malls, office buildings, hotels, etc., to ensure the safe operation of equipment and improve the stability of commercial operations.
3. Public facility guarantee: Provide protection for the power distribution system of public buildings such as hospitals, schools, and sports centers, ensure the reliable operation of medical equipment, teaching facilities, etc., and maintain the normal operation of public services.
4. New energy grid connection system: In distributed photovoltaic, wind power and other new energy grid connection systems, as a grid connection protection device, it realizes the functions of voltage loss tripping and voltage detection closing, which meets the requirements of grid connection.
5. Agricultural production electricity: Provide protection for three-phase electrical equipment such as agricultural irrigation pumps and agricultural product processing equipment, adapt to the complex rural power grid environment, and ensure the smooth progress of agricultural production.

Technical Data

Rated supply voltage	AC 220V	Operation voltage range	AC 80V~350V
Rated frequency	50/60Hz	Overvoltage(>U)setting range	230~300V
Overvoltage(>U)setting range	210~140V	Rated Current	40/63A(subject to prodect label)
>U And	0.5S	Reset/Start Delay	1~600S
Voltage measurement accuracy	2%(Not exceeding 2% of the overall range)	Rated Insulation Voltage	400V
Output contact	1NO	Electrical life	10⁵
Mechanical life	10⁶	Protection Degvree	IP20
Pollution Degree	3	Altiude	≤2000m
Operatintg temperature	-50℃ ~ 55℃	Humidity	≤50%at40 ℃ (without condensation)
Storage temperature	-30℃ ~ 70℃

Default Setting

Technical Parameter	Setting range	Step	Factory Setting
Over-Voltage Protection Value	230~300V	1V	280V
Under-Voltage Protection Value	210~140V	1V	160V
Recovery delay time	1~600s	1s	5s
